100W LED Street Light

Source: https://www.oakled.com/product/100w-led-street-light/

OAK-SL-100W
Manufacturer of 100W LED street light over 10 years
Light cover 15-60m, 15-60m pole distance optional, no darkness on the ground
Cree COB chips from USA original, Meanwell driver adapted
Over 70% energy saving compared with conventional lamps, extreme energy saving
High tech thermal system, provide the best heat dissipation environment, extend lifespan
Lifespan over 100,000h
Working with -40 to +60°C environment temperature
0-10V dimming standard or DALI, DMX, PWM dimming available upon request for 90-305V.
5 years warranty
MN
Power
(W)
Light Cover
Efficiency
Dimming
Options
Color
Temperature
Specification
OAK-ST-60W
60
10-20m
170lm/w
PWM
DALI
DMX
Zigbee
1700-10,000K
Input Voltage: 90V~305V AC
Waterproof Rating: IP67
Lifespan: >100,000hrs
Power Factor: ≥0.95
Frequency: 50~60HZ
Working Temp.: -40 ~ +60°C
OAK-ST-80W
80
10-20m
OAK-ST-90W
90
10-20m
OAK-ST-120W
120
10-40m
OAK-ST-150W
150
10-50m
OAK-ST-200W
200
10-50m
OAK-ST-240W
240
10-70m
OAK-ST-300W
300
10-70m
Parameters
Model No.
OAK-SL100
Light Source
Cree COB Original
Driver
Meanwell
Power
100w
Luminous Efficiency
170 lm/W
Luminous Flux
17,000 lm
Input Voltage
90~305V AC
Color Temperature
1700~100,00K
CRI
≥80
IP Rating
IP67
Lifespan
>100,000h
Power Factor
≥0.95
Power Efficiency
≥93%
Power Frequency
50~60HZ
Working Temp.
-40 ~ +60°C
MH reference Replacement
250-400W
Performance
OAK LED Street lights suitable for 15-60m pole distance
high uniformity
no blackness on the ground
High Efficiency
with the lowest power to reach the same or higher brightness
Curved surface design
High wind resistance, high stability, suitable for storm typhoon weather
Wide installation angle
180 degree adjustable
Project References
OAK LED Street Light is optimized for customers requiring a LED solution for major roadways, highways, buildings, etc.
Curved surface design makes a higher wind resist ability and stability than conventional street light with panel design.
Unique reflective optics are designed to optimize application efficiency and minimize glare.
Modern design incorporates the heat sink directly into the unit for heat transfer to prolong LED life, which can significantly reduce maintenance needs and expense over the life of the fixture.
Quality Control
•Before shipment, our QC department must control all led light in high level of quality.
All our led series keep unceasingly for 48 aging hours testing keep our reinforce dissipation system.
Customized Service
• 100% customize for different pole distance and pole height.
• OEM brand service is available.
Warranty
• 5 Year Standard
• 10 Year Optional
Applications
• Designed to meet recommended luminance and illuminance requirements for roadway, pedestrian and alley ways, streets and highways.
Area and site lighting for parking lot, playground, sport area, campuses etc available.
